- The transmission mechanism is provided with 2 main rails, 2 auxiliary rails and 12 equilibrium points as a whole Kit.
- In the gap between the rails and the clamps there is a piece movable phosphor-bronze for enhanced friction resistance leading to stable trips.
- The foam tank and the pre-heater are adjusted synchronously
- The tin tank is retractable off the machine base for easy cleaning and maintenance.
- The circuitry is controlled by S.C.R. for upgraded stabilityad energy-saving.
- The temperature control is conducted by the P.I.D. micro-computer for its zero-tolerance.
- Three-set twin-temperature control, IR Pipe pre-heating for instant temperature raise to meet the level demanded by the panel.
- Safety insulation glass for extended duration of the pre-heating piping.
- The pre-heating piping is removable independently for easy maintenance and service.
- The ball bearing, changeover tin nozzle meets perfectly the S.M.T (chip) multi-ply board, single board as demanded by the perfect soldering.
- The changeover static wave peak changes the size and direction of the contact face of the nozzle according to the size of the basilar plate of the products.
- Independent front (rear) rails with synchronized hydraulic cylinders for angle adjustment and precision shifts.
- Easy and fast change of width of the basilar plate producing no hydraucone.
- The wholly concealed bearings, shaft rods and the gearing keep off stains while providing easy maintenance for extended life span.
- The rear auxiliary conveyor rail is available for the transfer of the unit, after welding the board so as to keep the clamps from being vulnerable to damages and deformation of the basilar plate while keeping the same from being subject to impacts.
- The powerful transverse cooling fan meets the demand of dissipation of the panel.
|
